DXF File: 1200 x 2400 x 100 5mm Welding Bench (Fixture Weld Table)

$7.50

Assembled Size: 1200 × 2400 × 100mm 90D Metric

16mm Holes, 25mm Spacing

This listing is for a downloadable DXF file

The design allows you to cut all the components needed to build your own precision welding bench. Simply take the DXF file to your CNC laser or water jet cutter to produce the parts and assemble your custom bench.

✔ Slot-and-tab design for simple, accurate assembly
✔ Precision holes for use with standard fixture table clamps, pins, and accessories
✔ Strong, stable construction to hold materials square while welding
✔ Download instantly and cut as many as you need

Assembly is straightforward:

  • Quick hot tacks in the designated slots will hold the table together

  • Minimal welding required (to reduce distortion)

  • Components fit snugly, ensuring accuracy

Please Note:

  • DXF file only – no physical item included

  • Instant download after payment

  • Due to the nature of digital files, returns, exchanges, or cancellations are not accepted

Add To Cart
